Stephuit N
Product information
A profile plank system which is suitable for a wide range of applications, characterised by the good anti-slip properties of its surface features. Suitable for use in all applications, including public access areas where small perforations are a requirement.
Technical data
Dimensions
|
Material |
Sheet Thickness |
As class |
|
Raw / hot-dip galvanised steel[DD11] |
2,0 / 2,5 / 3,0 |
R13 |
|
Sendzimir galvanised steel [DX51] |
2,0 / 2,5 / 3,0 |
R13 |
|
Aluminium [AIMg3] |
2,5 / 3,0 |
R13 |
|
Stainless steel [1.4301] |
2,0 |
- |
|
preferred widths |
182 / 240 / 298 / 356 variabel |
|
|
preferred heights |
40 / 50 / 75 / 100 Other heights on request |
|
|
lengths |
max. 6.030 mm |
|
|
length divider |
45 |
|
Special sizes or materials on request. Stored sizes according to stock list.
All data in mm.
